Hyundai Elantra (CN7): Interior Lights / Rear lamp
Rear Room Lamp (
):
NOTICE
Do not leave the lamp switches on for an extended period of time when the engine is turned off.
(1) Front Map Lamp (2) Front Door Lamp (3) Front Room Lamp ON (4) Front Room Lamp OFF Front map lamp: Press either of these lens to turn the map lamp on or off.
The luggage compartment lamp comes on when the trunk is opened. NOTICE The luggage compartment lamp comes on as long as the trunk is open. To prevent unnecessary battery system drain, close the trunk securely after using the luggage compartment.
